PSU SEASONIC SSR-500PL

Форма фактор: Intel ATX 12 V

AC вход: Voltage: 100 V – 240 V; Current: 7－4 A; Frequency: 50 Hz – 60 Hz

DC изход: Rail:+3.3 V/+5 V/+12 V/-12 V/+5 VSB; Maximum Power:20 A/20 A /41 A/0.3 A/3 A 100 W/492 W/3.6 W/15 W; Total continuous power:500 W

Конектори: MB (24/20 pins)-1-610-1; CPU-650 CPU (8/4 pins)-1-650-2; PCIe (8/6 pins)-2-750-0; PCIe (8/6 pins)-1-750-2; SATA-4-860-1; SATA-4-810-1; SATA-4-760 -0; SATA-2-700-0; SATA-2-570-0; SATA-2-470-0; SATA-2-450-0; Molex-3 -690-1; Molex-2 -470-1; Molex to SATA 3.3 Adapter-2-300; Molex to FDD Adapter-1-101 -1

Информация за вентилатора: N/A

Информация за кабела: Modularity:Fully Modular; CWebbed cables (MB, CPU, PCIe): Flat black cables

Характеристика: Operating Temperature:0 – 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C); MTBF @ 25 °C, excl. fan:150,000 hours; AC Input:Full Range; Protection:OPP, OVP, UVP, OCP, OTP, SCP

Безопасност и опазване на околната среда: Safety and EMC:cTUVus, TUV, CB, CCC, BSMI, EAC, CE; Environmental Compliance:Energy Star, RoHS, WEEE, ErP Lot 6, REACH

Размери: 140 mm (L) x 150 mm (W) x 86 mm (H)

Производител: SEASONIC
