Stonet P124GC is a 26 Ports standard POE switch that provides 24 GE POE ports and 2 SFP Up-link ports. Ports 1~24 features POE power supply capability and can be used as Power over Ethernet devices. The power supply port can automatically detect and recognize the powered device that complies with the IEEE 802.3af/at standard and supply power through the network cable. 2 SFP up-link ports are compatible with both optical fiber or network cables with different module. Gigabit transmission rate ensure a smooth transmission for NVR or up-link routers. P124GC is a most powerful solution for HD security network and high speed wireless network systems.
Features
- Supporting 802.3, 802.u Faster Ethernet, IEEE 802.3ab 1000BASE-T
- Supports POE IEEE 802.3af/at compliant Powered Device (PD)
- Modes: Normal switch mode/ Watch dog model (automatically manage CCTV cameras power supply)/ VLAN model
- Ports 1~24 gigabit ports features POE power supply capability and can be used as Power over Ethernet devices; 2x1000Base-X SFP
- Support full duplex based on IEEE802.3x and half duplex based on Backpressure
- Auto MDI/MDIX crossover for all ports
- Support non-blocking wire speed forwarding
- MAC address auto-learning & auto-aging
- Steel case, the total POE power budget of 320W
- Just Plug and Play
Specifications
- Interface: 24×10/100/1000M POE ports (Data/Power); 2x1000M uplink SFP slot port (Data)
- Mode: Normal switch mode/ VLAN & watch dog model
- Data Transfer Rate: Ethernet: 10Mbps (Half-duplex); 20Mbps (Full-duplex); Fast Ethernet: 100M
