PSU SEASONIC SSR-550PX PLATIN

Форма фактор: Intel ATX 12 V

AC вход: Voltage: 100 V – 240 ; Current: 8 – 4 A; Frequency: 50 Hz – 60 Hz

DC изход: Rail:+3.3 V/+5 V/+12 V/-12 V/+5 VSB; Maximum Power:20 A/20 A/45 A/0.3 A/3 A; 100 W/540 W/3.6 W/15 W; Total continuous power:550 W

Конектори: MB (24/20 pins):1-610-1; CPU (8/4 pins):1-650-1; PCIe (8/6 pins):2-750-1; PCIe (8/6 pins):1-750-0; SATA:4-810-1; SATA:4-800-0; SATA:4-760 -0; SATA:2-700-0; SATA:2-570-1; SATA:2-470-0; SATA:2-450-0; Molex:3-690-1; Molex:2-470-0; Molex to SATA 3.3 Adapter:2-300-0; Molex to FDD Adapter:1-101 -1

Информация за вентилатора: Fan Size:120 mm; Fan Control:Premium Hybrid Fan Control; Fan Bearing:Fluid Dynamic Bearing; Life Expectancy:50,000 hours at 40 °C, 15 % – 65 % RH

Информация за кабела: Modularity:Fully Modular; Cable type:Flat black cables

Характеристика: Operating Temperature:0 – 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C); MTBF @ 25 °C, excl. fan:100,000 hours; AC Input:Full Range; Protection:OPP, OVP, UVP, OCP, OTP, SCP

Безопасност и опазване на околната среда: Safety and EMC:cTUVus, TUV, CB, CCC, BSMI, EAC, CE; Environmental Compliance:Energy Star, RoHS, WEEE, ErP Lot 6, REACH

Размери: 140 mm (L) x 150 mm (W) x 86 mm (H)

Производител: SEASONIC

Гаранция: 99 месеца
