Форма фактор: Intel SFX 12 V / ATX 12 V
AC вход: Voltage: 100 V – 240 V; Current: 9 – 4.5 A; Frequency: 50 Hz – 60 Hz
DC изход: Rail:+3.3 V +5 V +12 V -12 V +5 VSB Maximum Power:20 A/20 A/54 A/0.3 A/3 A; 100 W/648 W/3.6 W/15 W; Total continuous power/l650 W
Конектори: MB (24/20 pins)350 mm:1; CPU (8/4 pins)400mm:1; PCIe (8/6 pins)500mm:2; SATA-600mm:2; Molex-700mm:1; Molex to FDD Adapter-101:1
Информация за вентилатора: Fan Information Fan Size:120 mm; Fan Control:Premium Hybrid Fan Control; Fan Bearing:Fluid Dynamic Bearing; Life Expectancy:50,000 hours at 40 °C, 15 % – 65 % RH
Информация за кабела: Modularity:Fully Modular; Cable type:Flat black cables
Характеристика: Operating Temperature:0 – 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C); MTBF:@ 25 °C, excl. fan 100,000 hours; AC Input:Full Range; Protection:OPP, OVP, UVP, OCP, OTP, SCP
Безопасност и опазване на околната среда: Safety and EMC:cTUVus, TUV, CB, CCC, BSMI, EAC, CE; Environmental Compliance:Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Размери: 125 mm (W) x 125 mm (L) x 63.5 mm (H)
Производител: SEASONIC
Гаранция: 96 месеца
