производител: SEASONIC
Форма фактор: Intel ATX 12 V
AC вход: Voltage: 100 V – 240 V; Current: 7-4 A; Frequency: 50 Hz – 60 Hz
DC изход: Rail:+3.3 V/+5 V/+12 V/-12 V/+5 VSB; Maximum Power:20 A/20 A /37 A/0.3 A/3 A; 100 W/444 W/3.6 W/15 W; Total continuous power:450 W
Конектори: MB (24/20 pins):1-610-1; CPU (8/4 pins):1-650-1; PCIe (8/6 pins):2-750-0; PCIe (8/6 pins):1-750-2; SATA:4-860-1; SATA:4-810-1; SATA:4-760 -0; SATA:2-700-0; SATA:2-570-0; SATA:2-470-0; SATA:2-450-0; Molex:3-690-1; Molex:2 -470-0; Molex to SATA 3.3 Adapter:2-300 -1; Molex to FDD Adapter:1-101 -0
Информация за кабела: Modularity:Fully Modular; Cable type:Webbed cables (MB, CPU, PCIe); Flat black cables
Характеристика: Operating Temperature:0 – 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C); MTBF @ 25 °C, excl. fan:150,000 hours; AC Input:Full Range; Protection:OPP, OVP, UVP, OCP, OTP, SCP
Безопасност и опазване на околната среда: Safety and EMC:cTUVus, TUV, CB, CCC, BSMI, EAC, CE; Environmental Compliance:Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Размери: 140 mm (L) x 150 mm (W) x 86 mm (H)
Производител: SEASONIC
Гаранция: 96 месеца
