Форма фактор: Intel ATX 12 V
AC вход: Voltage: 100 V – 240 V; Current: 10 A Max.; Frequency: 50 Hz – 60 Hz
DC изход: Rail“+3.3 V/+5 V/+12 V/-12 V/+5 VSB; Maximum :15 A/15 A/62 A /0.3 A /2.5 A; 100 W/744 W/3.6 W/12.5 W; Total continuous power:750 W
Конектори: MB (24/20 pins):1/550/1; CPU-650 CPU (8 pins):1/700/1; CPU-650 CPU (4/8 pins):1/600/1; PCIe (8/6 pins):2/700/2; PCIe (8/6 pins):1/750/0; SATA:4/810/0; SATA:4/860/0; SATA:4/760 /0; SATA:3/690/2; SATA:2/700/0; SATA:2/600/0; SATA:2/470/0; SATA:2/450/0; Molex:3/690/1; Molex:2/470/0; Molex to SATA 3.3 Adapter:2/300/0; Molex to FDD Adapter:1/101 /0
Информация за вентилатора: Fan Size:120 mm; Fan Control:Smart and Silent Fan Control; Fan Bearing:Sleeve Bearing; Life Expectancy:25,000 hours at 40 °C, 15 % – 65 % RH
Информация за кабела: Modularity:Fixed cables; Cable type:Flat black cables
Характеристика: Operating Temperature:0 – 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C); MTBF @ 25 °C, excl. fan:100,000 hours; AC Input:Full Range; Protection:OPP, OVP, OCP, SCP
Безопасност и опазване на околната среда: Safety and EMC:cTUVus, TUV, CB, CCC, BSMI, CE, FCC Environmental Compliance:Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Размери: 140 mm (L) x 150 mm (W) x 86 mm (H)
Производител: SEASONIC
Гаранция: 60 месеца
