производител: FORTRON
Производствена част №: SPA6005801
Модел: FSP600-50ARN(80)
Форма фактор: ATX 12V v2.3
AC вход: Input Frequency:47 ~ 63 Hz; Input Current:230V@ 4.0 Amps-rms maximum.
DC изход: +3.3V 20Ms (maximum); +5V 20Ms (maximum); +12 V 20Ms (maximum); -12 V 20Ms (maximum).
Конектори: ATX12V 24 Pin x 1; ATX12V 20+4 Pin x 0; CPU 8 Pin x 0; CPU 4+4 Pin x 1; CPU 4 Pin x 0; PCI-E 2.0 6+2(8) Pin x 2; PCI-E 2.0 6 Pin x 2; S-ATA x 6; Molex 4 Pin x 2; Floppy 4 Pin x 1; Fan 2 Pin x 0.
Тип PFC: Active
Информация за вентилатора: Fan size: 120 mm; Low ripple & noise
Информация за кабела: Power cable: No
Характеристика: Efficiency Level:EU 230V 80Plus Bronze; Erp Lot:<0.5W; Input Voltage:230Vac; Effciency:85%@ 20% load; 88%@ 50% load; 85%@ 100% load; Temperature Range: Operating : 0 to +40℃,Storage :-40 to +70℃; Humidity:Operating : 85% to % RH, Non-condensing,Storage : 95% to % RH, Non-condensing; MTBFThe power supply reliability, when calculated by “Bellcore” latest revision are exceed 100,000 hours with all output at maximum load and an ambient temperature of 25℃.
Безопасност и опазване на околната среда: CE,TUV
Размери: 140x 150x 86 mm
Производител: FORTRON
Гаранция: 24 месеца
