AC вход: Input voltage: 100-240V C; Input frequency: 50-60 Hz; Input current: 10A/5A
DC изход: 3.3V: 22A; 5V: 22A; 3.3V and 5V combined: 120W; 12V: 63.3A; -12V: 0.3A; +5Vsb: 3A; Total Power: 760W
Конектори: ATX 24-pin: 1; ATX12V 4+4 pin / EPS12V 8-pin: 2; PCIe 6+2 pin: 6; SATA: 10; Peripheral: 4; ATX 20+4 pin: 600 mm; ATX 12V 4+4 pin: 700 mm; EPS12V 8-pin: 600 mm; PCIe 6+2 pin: 550 + 120 mm; SATA: 400+150+150+150 mm & 650+150mm; Peripheral: 400+150+150+150 mm
Информация за вентилатора: 140 mm FDB bearing Fractal Design Dynamic series fan
Информация за кабела: Modular 24-pin cable: Black UltraFlex™ wires in braided sleeve Other modular cables: Flat black UltraFlex™ wires
Характеристика: Over voltage protection, Under voltage protection, Overpower protection, Short circuit protection, Over current protection, Over temperature protection
Безопасност и опазване на околната среда: ErP 2013 (<0.45W @230. VAC, 45 mA load on +5Vsb);CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, KC+KCC
Размери: 150 x 150 x 86 mm
Производител: FRACTAL DESIGN
