PSU FD 650W ION SFX

Форма фактор: SFX-L

AC вход: Input voltage:100-240V AC; Input frequency:50-60 Hz; Input current:8A/4A (650G)

DC изход: 3.3V-20A; 5V-20A; 3.3V and 5V combined-100W; 12V-54A; -12V/0.3A; +5Vsb/3A; Total Power:650W

Конектори: ATX:1; EPS/ATX12V:1; PCIe:4; SATA:8; Peripheral:2;Cable Configuration (length in mm between connectors): ATX 24-pin:350; EPS/ATX12V 4+4 pin:400; PCIe 6+2 pin:400+100 x2; SATA:300+200+200+100 x2; Peripheral:300+200

Информация за вентилатора: Slim (15 mm) FDB bearing 120 mm fan;Maximum operating temperature (full load):40°C – Maximum 80% load at 50°C; Semi-passive operation:Yes (Zero RPM); Capacitors:105°C Japanese Polymer; Life expectancy (MTBF) at max output load:100,000 hour

Информация за кабела: Fully modular;Modular 24-pin: Braided sleeve UltraFlex™ wire – Others: Flat UltraFlex™ wire

Характеристика: Over voltage protection – Under voltage protection – Over power protection – Short circuit protection – Over current protection – Over temperature protection

Безопасност и опазване на околната среда: Standby efficiency:ErP 2013 (<0.45W @230 VAC, 45 mA load on +5Vsb); Sleep State Compliance:C6/C7; Approvals & Certifications:CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE

Производител: FRACTAL DESIGN
