24-портов L3 управляем комутатор PoE+ с 4 10G слота TP-Link Omada SG6428XHP

Интерфейс: 4× 10G SFP+ Slots; 1× USB Type-C Console Port; 2× USB 2.0 Ports; 1× RJ45 Management Port; 24× 10/100/1000 Mbps PoE+ RJ45 Ports; 1× RJ45 Console Port

L3 Превключващи функции: Max 1,024, IPv6: Max 512; Relayed Interface; VRRP: Version v2/v3, Max 64 groups; Dynamic ARP: 7,680 dynamic entries; IPv4: Max 256, IPv6: Max 256; Relayed VLAN; OSPF: Version v2/v3; v2: Max 8,190, v3: Max 4,097; RIP: Version v1/v2, Max 8,190; DHCP Server/Relay; Proxy ARP; Max 1,000 Manual Binding Entries; DHCP Server:; IP Interfaces:; Static ARP: 512 static entries; Host Route Table: Max 6,100 entries; Max 64 IP Pools; Static Routing; ECMP: 256 entries, max 32 ECMP Nexthops per Destination

Качество на обслужване: Voice VLAN; Class of Service; User-Defined OUI; Bandwidth Control; Smoother Performance; Action for Flows

+ Подарък: N

VLAN: Voice VLAN; Multicast VLAN; VLAN VPN (QinQ): Max 256 entries; Max. 4K VLAN Groups; VLAN VPN (QinQ); Management VLAN; Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries; MAC VLAN Entries: 200; GVRP; Private VLAN; 802.1q Tagged VLAN

L2 комутационни функции: 802.3x Flow Control; Multicast Filtering; MAC Address Table; Multicast VLAN Registration (MVR); Port-based and VLAN-based Loopback Detection; PIM-DM, PIM-SM (IPv4); ERPS; RSPAN; MLD Snooping; Static Multicast IP; L2 Multicast Table; Supports 2,048 IGMP groups; Static Link Aggregation; IGMP Snooping; Spanning Tree Protocol; Multicast; Fast Leave

Експлоатационни качества: Table of MAC addresses 32 K; Stacking Number: 4; Stack Bandwidth: 20 Gbps Per Port (Full-Duplex); Packet Buffer Memory 3MB; Switching capacity 128 Gbps per Unit; Jumbo shot 9 KB; Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports); Data packet transmission rate 95.2 Mpps

Ethernet портове: 4× 10G SFP+ Slots; 1× RJ45 Management Port; 24× 10/100/1000 Mbps PoE+ RJ45 Ports; 1× RJ45 Console Port

Марка: TP-LINK

Работна температура: -5 °C to 50 °C (23 °F to 122 °F) @ 300 meters; -5 °C to 40 °C (23 °F to 104 °F) @ 3,000 meters; -5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters

Софтуерни функции: L3 Features; VLAN; Advanced Features; L2 and L2+ Features; Quality of Service; Security

Захранване: wo Field-replaceable and Hot-swappable Power Supply Modules** (100–240 VAC, 50/60 Hz); **Shipping with one PSM500-AC module by default, and another field-replaceable redundant power supply requires purchasing separately.

Вид на монтаж: Rackmount

Размери дълбочина: 380 mm

Влажност на съхранение: 10%~90% без кондензация

Размери ширина: 440 mm

Критерии за валидност на гаранцията: Гаранционна карта/Сериен номер

Работна влажност: 10%~90% без кондензация

Размери височина: 44 mm

Системни изисквания: Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.

24-портов L3 управляем комутатор PoE+ с 4 10G слота TP-Link Omada SG6428XHP

Производител: TP-LINK

Гаранция: 60 месеца
